Door unlock button (
opened. This button is only active when the machine is idle and the water in the machine is below
door level.
Touchscreen for the MilTouch™ controller — This is a touch-sensitive display screen that
you use for most machine functions.
BNVLUO01 / 2018513
2.2

Emergency Stop Switch (locking push button)

One or more emergency stop switches (pictured below) may be provided on the device. When
pressed, any emergency stop switch removes power from the machine controls, stops the ma-
chine, and locks in the depressed (switch actuated, machine stopped) position. When safe to do
so, turn the button clockwise to unlock the switch. To resume operation, perform the device's nor-
mal startup procedure.
Figure 2. Emergency Stop Switch
Stopped Position
NOTICE: Press the emergency stop switch immediately in an emergency situation.
Display or Action
BNCLJO10 / 2021172
2.3 How to Use the MilTouch™ Controller
The Milnor ® MilTouch™ washer-extractor controller uses a touch-sensitive display screen to op-
erate the machine. All the functions and information you need to process goods appear on this
screen.
Pellerin Milnor Corporation
) — This button frees the door latch so the door can be unlatched and
Explanation
This symbol represents the emergency stop switch in Milnor
documents other than electrical wiring diagrams.
BNVLUO01 0000189558
BNVLUO01.C01 0000189557 C.2 B.4 F.2 12/9/20 9:19 AM Released
Run Position
BNCLJO10 0000212821 D.4
BNCLJO10.C01 0000212820 C.2 D.4 C.3 9/11/20 8:32 AM Released
Controls
