CIRCULAR SAW
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europe's leading suppliers.
All products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive warranty.
We hope you will enjoy using this product for
many years to come.
The pictures mentioned in the text are
corresponding with the pictures at page 2
For your own safety and for the safety of
others, please read these instructions
carefully before using this appliance. It
will help you understand your product
more easily and avoid unnecessary
risks. Keep this instruction manual in a
safe place for future use.
Contents
1. Machine data
2. Safety instructions
3. Assembly and adjusting instructions
4. Operation
5. Maintenance
1. MACHINE DATA
Technical specifications
Voltage
Frequency
Power input
No load speed
Saw blade dimensions
Number of teeth
Max sawing depth 90°
Max sawing depth 45°
IP Class
Weight
Lpa (sound pressure level) 92.8+3 dB(A)
Lwa (sound power level)
aw(vibration value)
Ferm
230 V
50 Hz
1200 W
5000/min
Ø185xØ20x2.4 mm
Z24
65 mm
43 mm
IP 20
3,47 kg
103.8+3 dB(A)
3.787+1.5 m/s
2
Product information
Fig. A
1. Handgrip
2. On/off switch
3. Cut depth clamping knob
4. Power cord
5. Saw blade safety guard
6. Hexagon screw
7. Soleplate
8. Retaining ring
9. Saw blade
10. Rip fence
11. Rip fence clamping knob
12. Sawing angle clamping knob
13. Shaft locking knob
14. Protractor
15. Knob
16. Safety switch
17. Carbon brush screw
Contents of packing
1 Circular handsaw
1 Rip fence
1 TCT Saw blade Ø185 mm
1 Allen key
1 Set carbon brushes
Check first whether or not the delivery has been
damaged by transport and/or whether all the
parts are present.
2. SAFETY INSTRUCTIONS
Explanation of the symbols
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
Keep bystanders away
Wear ear and eye protection
