SPARE PARTS LIST FRS-800K
Nr.
Description
408579
Adjustable bottom plate
408580
Rubber cover
408581
Bearing
408582
Bearing
408583
Shaft + gear
408584
Sliding bar + clamp
408585
Bearing
408586
Rotor
408587
Stator
408588
Brush holder
408589
Carbon brush (set)
408590
Speed controller
408591
Switch
62
Position
2
6
11
12
14+15
18+19
26
32
35
36
37
44
46
Ferm
RECIPROCATING SAW
THE NUMBERS IN THE FOLLOWING TEXT COR-
RESPOND WITH THE PICTURES AT PAGE 2
Table of contents
1. Machine data
2. Safety instructions
3. Operation
4. Maintenance
1. MACHINE DATA
TECHNICAL SPECIFICATIONS
Voltage
| 230 V~
Frequency
| 50 Hz
Power input
| 800 W
No load speed
| 600-2500/min
Maximum cutting thickness
| 150 mm
Stroke length
| 28 mm
Weight
| 3.8 kg
Lpa (sound pressure level)
| 90,2 dB(A)
Lwa (sound pressure capacity) | 103,2 dB(A)
Vibration value
| 10,675 m/s
2
PRODUCT INFORMATION
Fig.A
1. Blade
2. F ootplate
3. Blade clamp screw
4. Trigger switch
5. Speed controller
6. Trigger lock button
7. Mains lead
8. Footplate length adjustment screws
9. 4 mm hexagon key
2. SAFETY INSTRUCTIONS
The following pictograms are used in these instructions
for use:
There is danger of material damage or bodily
injury.
There is a chance of electric shock.
The tool meets the safety requirements stated in
the applicable European guidelines.
Class II equipment – Doubly insulated – An eart-
hed plug is not necessary
Ferm
The revolutions of the machine can be electroni-
cally regulated.
Read the instructions.
Wear safety glasses.
Wear ear protection.
Faulty and/or discarded electrical or electronic
apparatus have to be collected at the appropriate
recycling locations.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual and the enclosed documentation with
the machine.
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Keep these instructions in a safe place!
ADDITIONAL SAFETY INSTRUCTIONS
The machine must not be damp and must not be
operated in a wet environment. Always inspect
cable and plug before using machine. Only have
damage repaired by a qualified professional.
Only insert the plug into the mains socket when the
machine is switched off. Wear protective gloves and
sturdy footwear.
Do not saw materials containing asbestos!!!
•
Wear protective goggles when working with mate-
rials which produce large amounts of chips.
•
Wear a protective mask when sawing other fibrous
materials.
•
Portable equipment used outdoors must be connec-
ted with a fault-current circuit breaker.
•
Extension cables and plugs must be approved for
outdoors.
•
Remove adjusting keys and wrenches before turning
the tool on.
•
Secure your workpiece with clamps. Always lead
cable away from machine towards the rear.
•
Move machine towards the workpiece only when
switched on.
•
Always hold machine with both hands and ensure
that you have a safe footing while working.
•
The machine may be operated only with the foot
plate mounted. When sawing, the foot plate must
always rest on the workpiece.
•
Always remove the plug from the mains socket
before carrying out any work on the machine.
•
Do not carry the machine by the cable.
3
