Note: Console has to be location division setting so that the
directions on the sensor are matching with your real location.
Permanent wind direction error(read approximately 180º)will be
introduced when the wind direction sensor is not positioned correctly
during installation.
Fasten the integrated transmitter to mounting pole brackets with foot-
mounting, two ¢3 bolts and M3 nuts , as shown in Figure 15
Figure 15
Tighten the mounting pole to your mounting pole(purchased separately)
with the four¢5 Bolts and M5 Nuts assembly, or fix on the wall with four
tapping screw,as shown in Figure16.
16
