PARTS LIST

No. Description
1 Main frame
2 Front base
3 Rear base
4 Rear base levelling pad
5 Bolt m8xl74
6 Curved washer Φ8.5x1.5x
φ25xr33.5
7 Nut M8
8 Crank
9 L/R Left/right pedal
10 Front base cap
11 Computer cable
12 Resistance adjustment cable
13 Connecting cable
14 Internal hexagonal bolt m8x16
15 Saddle height adjustment sleeve
16 Handlebar angle adjustment
handle
17 Handlebar column
18 Front handlebar column cover
19 Flat washer
20 Cross-head bolt
21 Cross-head bolt m4x10
22 Handlebar column cover
23 Handlebar cap
24 Computer
Quantity No. Description
1 25 Resistance adjustment knob
1 26 Handlebar foam
1 27 Steering wheel
2 28 Heart rate measurement cable
4 29 Saddle height knob
8 30 Separator
1 31 Flat washer D13xd8x1,5
1 32 Handlebar cover
1/1 33 Saddle
2 34 Saddle horizontal position guide
1 35 Saddle guide cap
1 36 Saddle column
1 37 U-bracket for horizontal saddle
positioning
4 38 Flat washer d10
1 39 Saddle horizontal position knob
1 40 Handlebar cover
1 41 Saddle
1 42 Saddle horizontal position guide
1 43 Water bottle
1 44 Water bottle holder
4 45 Screw
1 46 Flat washer
2 47 Towel holder
1
