Appliance description

Observe all safety and warning information during
operation (see Safety chapter).

3.1 System description

1
2
3
4
5
1. Inlet opening – air inlet turnable flap
2. Grease filters
3. Carbon filters (Only on DPR78C__)
4. Cooktop
5. Water collector
6
Appliance description
6. Metal sheet black canalization
7. Metal sheet telescopic extension
8. Vertical ducting
9. 90° bend duct
6
