Menu SET TEMPERATURE ROOM
To modify the setting please reference to paragraph "Set of the room temperature"
Menu SET POWER
To modify the setting please reference to paragraph "Set of the working power"
Menu CLOCK
To modify the settings use keys 1 and 2 and by pressing OK you confirm the data and go on to the following one. By activating the box
(flag) ON/OFF you enable the function chrono.
By last confirmation with OK you save all settings and return automatically to the screen with the icons.
Menu TIMER
With the function chrono thermostat is possible to program for each day of the week the switch on and off of the stove in four inde-
pendent intervals time. To enable the TIMER, see what is reported in the Clock menu.
In ducted stoves it is possible to set the temperatures of the individual rooms:
F (front) temperature of the stove installation room
R (Rear, single duct) room temperature heated by ducting
RL and RR (Rear Left and Rear Right for double ducting)
The EST (operation with external thermostat) and MAN (constant power operation) values can also be set
To choose the prog.tion use keys 1 and 2; confirms with OK.
Use keys 1 and 2 to modify the settings and by each press of OK you confirm the data and go on to the following one.
By last confirmation with OK you save all settings and return automatically to the screen with the icons.
Use and maintenance manual R 1000 Pro
1 TIMER program number
START: switch on time
STOP: switch off time
DAY: days of activation of the program
POWER: desired power at the time of switch ON of the stove
TEMPERATURE: setting of ambient temperatures
The symbol indicates that the chrono function is active. It is however possible
to program the chrono even if it is deactivated. To make it work, refer to the
chapter dedicated to setting the clock.
