IMPORTANT NOTES
This guide is an aid for the professional installation of the device.
Please note the following notes before installation:
• Always handle all parts of the device and the components of your vehicle with care.
• Under all circumstances observe the regulations of the vehicle manufacturer and do not
make any changes to the vehicle which could impair driving safety.
• For safety reasons, disconnect the vehicle battery's ground connection before installa-
tion.
• Please always pay attention to the correct polarity of the connections.
• Please do not modify any harnesses or connections of the device or the vehicle as this
may affect the warranty.
• Make sure that no cables are squashed or cause a short circuit.
• Do not lay cables in front of the airbags, e.g. in the dashboard or in a way that affects
their function.
NOTE:
For many vehicle models, a vehicle-specific 1-DIN installation set is required for professional
installation. In order to be able to use the existing steering wheel remote control of your ve-
hicle, a vehicle-specific adapter may also be required. You can obtain information about this
on the Internet or from your specialist dealer.
ACC-BUTTON
With the ACC button next to the SD card slot, you can operate the naviceiver without the
ignition switched on. Press the button for about 2 seconds and the device will turn on. To
switch off, press the button again for 2 seconds.
The ACC button is only accessible if you install the main device separately from the monitor
in the glove compartment. For this you need the separately available installation set VNA-
EXT-KIT100 (see page 10).
2
(ONLY IN CONNECTION WITH VNA-EXT-KIT100)
