If you have the TRÅDFRI gateway
or DIRIGERA hub
Go to App Store or Google Play and download
the IKEA Home smart app. The app will take you
through the process of installing your product and
other devices.
How to steer your lighting
When the product is connected to the mains, it is
possible to turn it ON/OFF with the main switch or
the foot switch, but if you want to dim or connect
your product to other IKEA Home smart products,
you need to buy a separate steering device (e.g. a
remote control).
The steering device needs to be paired with your
wireless product. If you have more than one (1)
wireless product, you can pair each one with the
steering device so that the entire combination can
be turned ON/OFF or dimmed at the same time.
Pairing a steering device to your product
1. Connect at least one (1) product to the mains
before you begin the pairing. Make sure that the
mains power is turned ON.
2. Locate the pairing symbol on the LED driver. Hold
the steering device close to the pairing symbol
(no more than 5 cm away).
3. Press and hold the pairing button on the steering
device for at least 10 seconds. A red LED light will
shine steadily on the steering device. The product
will begin to dim and flash one time to indicate
that it has being paired to the steering device.
How to factory reset your driver
If the product does not respond or if you want to
un-pair the product from a steering device, you
might have to perform a factory reset. The unit is
forced to factory reset by carefully pushing and
holding in the small button (marked RESET) with a
tip of pen on the LED driver enclosure and applying
slight pressure.
IMPORTANT!
• The product is for indoor use only and can be
used in temperatures ranging from 5 °C to 45 °C.
• Do not leave the product in direct sunlight or near
any heat source, as it may overheat.
• The declared radio range between the unit and
the steering device is measured in open air.
• Different building materials and placement of the
units can affect the wireless connectivity range.
Care instructions
To clean the unit, wipe with a dry soft cloth.
Never use abrasive cleaners or chemical solvents as
this can damage the product.
PRODUCT SERVICING
Do not attempt to repair this product yourself, as
opening or removing covers may expose you to
dangerous voltage points or other risks.
Save these instructions for future use.
Technical data:
Type: ICPSHC24-10EU-IL-2
Input: 220-240 VAC, 50/60 Hz, 0.1 A
Output: 24.0 VDC
Max total load: 0.42 A, 10.0 W
Radio range: 10 m in open air.
Operating frequency: 2400-2483.5 MHz
Output power: 12 dBm
Dimension, mm: 186x55x18.5 mm
Weight: 114 gr
Type of light source(s): LED
Efficiency in full-load: 85 %
No-load power consumption (Pno): 0.18 W
Networked standby power
consumption (Pnet): 0.18 W
Standby power consumption (Psb): N/A
Suitable as dimmer for light sources: Yes
Indoor use only
Manufacturer: IKEA of Sweden AB
(commercial registration number: 556074-7551)
Address: Box 702, SE-343 81 Älmhult, SWEDEN
The crossed-out wheeled bin symbol indicates that
the item should be disposed of separately from
household waste. The item should be handed in for
recycling in accordance with local environmental
regulations for waste disposal. By separating a
marked item from household waste, you will help
reduce the volume of waste sent to incinerators or
land-fill and minimize any potential negative impact
on human health and the environment. For more
information, please contact your IKEA store.
