ZENEC ZE-RCE3701-MK2 Montageanleitung

INSTALLATION MANUAL
CONNECTION DIAGRAM
ANSCHLUSSSCHEMA / CONNECTION DIAGRAM
RCA / Cinch
Video Signal (CVBS)
Fuse 0.5 A
Red: DC 6 ~ 24 V
Black: GND
RCA / Cinch
Video Signal (CVBS)
11.0 m
Fuse 0.5 A
KEY FEATURES
• Compact high resolution rear view camera for FIAT Ducato III
vehicles and type variants
• System design integrating the original Ducato brake light
retaining the road use homologation
• High quality Aptina CMOS picture sensor with low power
consumption
• Detailed high contrast picture under twilight conditions
• 11 m main wire length
TECHNISCHE SPEZIFIKATIONEN:
DE
• Mechanically adjustable cam angle, allowing field of view
Kamerasystem: ¼" / 6,4 mm Aptina
personalization
ASX340AT CMOS Sensor
• Plastic injection main housing with stainless steel fixation
Brennweite Linse: f 1,9
bolts
TV System: NTSC / 60 fps
Betrachtungswinkel: 170°(D) x 140°(H) x 85°(V)
DESCRIPTION
Native Sensor Auflösung: 720 (H) x 480 (V) Pixel
Auflösung Ausgangssignal: > 420 TV Linien
This ZENEC rear view camera model has been developed
Bildwiederholrate: 60 Felder/Sek.
for use with FIAT Ducato III based vehicle and motor homes
Signal/Rauschabstand: > 48 dB
in particular. This camera product deploys high quality parts
Lichtempfindlichkeit: 0.3 Lux
and materials though out, to provide reliable operation and
Video Ausgang: 1,0 Vp-p, 75 Ohm CVBS
appropriate longevity in the target vehicles mentioned.
Weißabgleich: Automatisch
Belichtungskompensation: Auto
The ZE-RCE3701-MK2 offers a large 150° diagonal viewing
Gamma Korrektur: 0.45
angle. The camera complies with a great variety of moni- and
Helligkeitsabgleich: Automatisch
Synchronisation: Automatisch
naviceiver models made for CVBS rear view cam signal input.
Spannungsversorgung: DC 6 - 24V
Schutzklasse: IP69K
Betriebstemperatur: -30°C ~ +75°C, RH 95% MAX.
CAUTION:
Use the included connection cable exclusively. Altering or replacing it will void your warranty.
BITTE BEACHTEN:
The camera is water- and dustproof and has been licensed according to the international standard IP69K. However, vehicle
Verwenden Sie ausschließlich das mitgelieferte Anschlusskabel. Bei
cleaning using high pressure water and steam jet devices may still lead to damage of IP69K rated camera models by water in-
Nichtbeachtung erlischt Ihr Garantieanspruch.
D e i K a m e a r t s i n a h c d r e D N I E N S h c u z t l k s a e s P I 6 9 K v r o
trusion. Keep a distance of at least one meter between the water nozzle and the camera housing.
gen von Schmutz- und Salzwasser geschützt. Sollte die Kamera jedoch
Hochdruckwasser-Reinigungsgeräten (Dampfstrahl) ausgesetzt werden,
können selbst IP69K spezifizierte Modelle durch eindringendes Wasser
beschädigt werden. Es ist daher ein Abstand von mind. 100 cm von der
Strahldüse einzuhalten.
ZENEC by ACR AG ∙ Bohrturmweg 1 ∙ CH-5330 Bad Zurzach ∙ Switzerland
EU Legal Representative: ACR S & V GmbH ∙ Industriestr. 35 ∙ D-79787 Lauchringen ∙ Germany
Manufacturer: ACR AG · Bohrturmweg 1 · CH-5330 Bad Zurzach · Switzerland
www.zenec.com
EU Legal Representative: ACR S & V GmbH · Industriestraße 35 · D-79787 Lauchringen · Germany
Rev.C
ZE-RCE3701-MK2 ZE-RCE3701-MK2
REAR VIEW CAMERA FOR FIAT DUCATO REAR VIEW CAMERA FOR FIAT DUCATO
COMPATIBLE WITH MODEL TYPE MODEL YEAR
Fiat Ducato III X250/X251 2006 − 2014
Fiat Ducato III X290 2014 − 2021
Fiat Ducato III Series 8 as of Q3 2021
Citroën Jumper II 250/250D/250DL as of 2006
Peugeot Boxer 250/251 as of 2006
30 cm
30 cm
3.5 mm
jack
3.5 mm
jack
Red: DC 6 ~ 24 V
TECHNICAL SPECIFICATIONS
Black: GND
Image device: ¼" / 6.4 mm Aptina
ASX340AT CMOS sensor
Lens focal length: f 1.9
TV system: NTSC / 60 fps
11.0 m
View angle: 150°(D) x 130°(H) x 85°(V)
Native sensor resolution: 720 (H) x 480 (V) pixels
Resolution of video-out: > 420 TV lines
TECHNICAL SPECIFICATIONS:
EN
Frame rate: 60 fields/sec.
Image device: ¼" / 6.4 mm Aptina
Signal to noise ratio: > 48 dB
ASX340AT CMOS sensor
Light sensitivity: 0.3 Lux
Lens focal length: f 1.9
Video output: 1.0 Vp-p, 75 ohms CVBS
TV system: NTSC / 60 fps
White balance: View angle: 170°(D) x 140°(H) x 85°(V) Auto
Native sensor resolution: 720 (H) x 480 (V) pixels
Backlight compensation: Auto
Resolution of video-out: > 420 TV lines
Gamma correction: 0.45
Frame rate: 60 fields/sec.
Gain control: Auto
Signal to noise ratio: > 48 dB
Sync system: Light sensitivity: 0.3 Lux Auto
Video output: 1.0 Vp-p, 75 ohms CVBS
Power supply: DC 6 - 24V
White balance: Auto
Current consumption: 40mA (DC12V) / ≤ 480mW
Backlight compensation: Auto
IP protection rating: IP69K
Gamma correction: 0.45
Operating temperature: - Gain control: Auto 30°C~+75°C, RH 95% max.
Sync system: Auto
Power supply: DC 6 - 24V
IP protection rating: IP69K
Operating temperature: - 30°C~+75°C, RH 95% max.
CAUTION:
Use the included connection cable exclusively. Altering or replacing it will
void your warranty.
d e m E n i d i r - n The camera is water- and dustproof and has been licensed accord-
ing to the international standard IP69K. However, vehicle cleaning
using high pressure water and steam jet devices may still lead to
damage of IP69K rated camera models by water intrusion. Keep
a distance of at least one meter between the water nozzle and the
camera housing.
INSTALLATION
1
1. Loosen the two Phillips cross recess screws
2
2. Remove the brake light reflector housing
Un-connect the white system plug of the vehicle
3
3. Screw in and tighten the stainless steel mounting
bolts by hand (5Nm). Use a dab of Loctite, if possible
4
Reverse
Speed In
IR In
ext. Mic
Power 300mA
GND
Audio In
Camera
CVBS In
E
4. Route the main cable from the naviceiver in the vehi-
cle cockpit / dashboard to the brake light opening in the
upper rear section of the vehicle. Fore power and RCA
video signal, the ZENEC Z-E3726 offers a direct system
"connector block E" which offers switched 300mA power
out's (see installation guide of ZENEC head unit).
ZE-RCE3701-MK2 ZE-RCE3701-MK2
REAR VIEW CAMERA FOR FIAT DUCATO REAR VIEW CAMERA FOR FIAT DUCATO
5
5. Connect the 3.5 mm jack output of the camera sensor
to the green counterpart on the main wire and wrap
around some isolating tape around it to prevent water
entering the connector
6
6. Connect the system plug with the connector
counterpart of the brake light reflector housing.
7
Re-mount the brake light reflector housing on
7.
top of the main camera housing, using the original
Philips cross-recess screws
8. (no picture)
After connecting the main cable to the control unit in the
dashboard > perform function test
9
Alignment of the camera ball at the bottom side
9.
of the camera main body if necessary, using the
supplied U-shaped tool
