Product Information; Identification Of The Products; Nameplates - Lenze MQA Serie Montage- Und Einschaltanleitung

Product information

Identification of the products

Nameplates

Product information
Identification of the products
Nameplates
Asynchronous servo motors
Pops. Contents
1 Manufacturer / production location
2 Motor type
4 Motor type
5 Technical data
5.2 Rated torque
5.3 Rated speed
5.4 Rated frequency
5.5 Rated voltage
5.6 Rated current
5.7 Maximum current
5.8 Rated power [kW]
5.9 Rated power [HP]
5.10 Continuous standstill torque
5.11 Power factor cos ϕ
8 Brake data
Type, supply voltage, electrical power consumption, braking torque
9 Feedback
10 Production data
10.2 Material number
10.3 Serial number
11 Bar code
12 Motor number
14 Additional motor specifications
14.1 Temperature class
14.2 Degree of protection
14.3 Motor protection
15 Applicable conformities, approvals and certificates
18 Year of manufacture / week of manufacture
22 C86 = motor code for controller parameterization (code 0086)
27 Permissible ambient temperature (e.g. Ta < 40°C)
40
l
1
2 4
5.8
5.5 5.2
5.6 5.9 5.10
5.7 14.2 14.1
9
8
10.2/10.3
18
15
5.4 5.3
5.11 22
14.3
27
12
11
