Vortice QE-B I Betriebsanleitung Seite 40

51
A
1
E
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
52
A
1
E
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
40
(*) (*)
2 3 L
B C
(*) (*)
2 3 L
(**)
B C
N
D
N
D
QE 100/60 LL ES
A Main terminal block
B 60m3/h switch
C 100m3/h switch
D Room light
E Main bipolar switch
QE 100/60 LL T ES
A Main terminal block
B 60m3/h switch
C 100m3/h switch
D Room light
E Main bipolar switch
