(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
(*) (*)
1 2 3
(**)
C
L N
QE 60/35 LL T ES
A Main terminal block
B 35m3/h switch
D
C 60m3/h switch
D Room light
E Main bipolar switch
