Vortice QE-B I Betriebsanleitung Seite 38

48
NORMAL MODE
A
1
B
F
L
N
COMFORT MODE
A
1
B
E
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
38
(*) (**)
2 3 L
C D
(*) (**)
2 3 L
C
QE 60/35 LL TP ES
N
E
N
D
A Main terminal block
B 35m3/h switch
C 60m3/h switch
D disable switch
E Room light
F Main bipolar switch
A Main terminal block
B 35m3/h - 60m3/h
double pole switch
C disable switch
D Room light
E Main bipolar switch
