Vortice QE-B I Betriebsanleitung Seite 26

29
A
(*)
1
B
F
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
30
A
B
C
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
26
(**)
2 3 L
C D
(*)
1 2 3
N
E
L N
QE 60/35 LL TP HCS
A Main terminal block
B 35m3/h switch
C 60m3/h switch
D disable switch
E Room light
F Main bipolar switch
QE 60/35 LL T PIR
A Main terminal block
B 35m3/h switch
C Main bipolar switch
