Vortice QE-B I Betriebsanleitung Seite 29

34
A
1
B
F
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
35
A
C
L
N
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(*) (**)
2 3 L
C D
(*)
1 2 3
B
N
E
L N
100
QE / 60 LL TP HCS
A Main terminal block
B disable switch
C 60m3/h switch
D 100m3/h switch
E Room light
F Main bipolar switch
100 60
QE / LL T PIR
A Main terminal block
B 60m3/h switch
C Main bipolar switch
29
