5.2 Changing air intake filters

2
1
Fig. 9 Changing intake air filters
unscrew the wing nut holding the filter lid (1) and remove the nut.
remove the filter lid (1) and the dirty air filter (2).
install the new air filter in place of the dirty one.
set the filter lid into place and tighten the wing nut.

5.3 Changing drive belt

22
1
2
Fig. 10 and 11 Changing drive belt
19
COMPRAG RECOM RCW series
