2.3 Function diagram and main components

7, 8
13
Fig. 1 Main components rCW.
1 pump unit
2 electric motor
3 air receiver
4 pressure switch
5 pressure gauge
6 Oil sight glass
7 Flywheel
8 Belt
9 Filter-regulator

2.4 Functional description

In one-stage models, air is fed into the cylinder along the discharge pipe, and then into the
pressure vessel.
In two-stage models, air is fed into the low-pressure cylinder and then into the pre-compres-
10
12
1 11 10
6
3
2
13
16
10 Check valve
11 Oil drain plug
12 Oil filling plug
13 air filter
14 air outlet ball valve
15 Condensate drain ball valve
16 plate compressor
17 plate receiver
18 Belt guard
18
4
5
9
15
17
14
Version 2.3
