pressor should be connected via a flexible hose.
All components of the compressed-air line must have a working pressure no less than the
compressor's nominal pressure.
Use a pressure vessel with a capacity corresponding to the compressor's performance and
the compressed air consumer.

3.5 Connecting to power supply

Connect the compressor to the electric mains: the plug of the compressor's power cable into
380 V socket.
Ensure that your electric power grid can withstand the starting current of the compressor.
An isolating switch must be fitted within reach of the compressor to facilitate connection and
maintenance.
3.6 Before use and on a weekly basis
Ensure the compressor's power cable is intact.
Ensure the oil level using the sight glass (point 3.7). Fill up with oil if necessary (point 5.1).
Fig. 5 Checking compressor's oil level
COMPRAG RECOM RCW series
The compressor must be earthed and protected against short
circuits in each phase, impermissible voltage fluctuation and
phase failure.
15
