3.3

Weighing Pan and Associated Components

Fig . 3: Analytical balance with analytical draft shield, precision balance with analytical draft shield, and precision balance with round draft shield (example)
Pos. Designation
1 Weighing pan
2 Pan support
3 Pan retainer
4 Shield disk
3.4

Conformity-assessed Devices

Some settings of conformity-assessed models are protected against user changes, e .g . external calibration for devices in accuracy
class II . This measure is intended to ensure the suitability of the devices for use in legal metrology .
3.5

Symbols on the Device

Symbol Meaning
NOTICE! Read the operating instructions .
1
2
4
3
Description
Optional accessory, only for analytical balances
Device Description
1
2
3
Entris ® BCE Operating Instructions
1
2
3
