When mounting the heater in front of a glass
panel, secure the heater against tilting by fixing
the mounting brackets on the pedestal of the
heater and the floor. (Fig. 4)
6 cm

Fixation to the floor

back
Push the bracket in the slits of the pedestal and
secure it with screws on the ground.
26
• Complete the connections as shown in the
• Connect the unit to the control unit. Make cer-
• Cover the terminal box of the heater with the
One the given alternatives to secure the
heater must be implemented!
Attachement
to the ground
Risk of injuries. Risk of equipment damag-
es through tilting of the heater.
Fig. 4
Fig. 5
EN
circuit plan. The circuit plan is affixed close to
the mains terminal.
tain that you have complied with the local le-
gal norms for safety and electric connections.
cover lid and secure it with 2 screws.
ATTENTION!
