MODEL
CHANNELS
CIRCUIT
CHANNEL A/B/C/D
OUTPUTPOWER RMS 13,8 V
Watts @ 4 / 2 Ohms
OUTPUTPOWER MAX 13,8 V
Watts @ 4 / 2 Ohms
CHANNEL E/F
OUTPUTPOWER RMS 13,8 V
Watts @ 4 / 2 Ohms
Watts @ 4 Ohms bridged
OUTPUTPOWER MAX 13,8 V
Watts @ 4 / 2 Ohms
Watts @ 4 Ohms bridged
Frequency Range –3dB
Damping Factor
Signal-to-Noise Ratio
Channel Separation
THD&N
Input Sensitivity
Input Impedance Low Level
Input Impedance
DSP Processor
High Level Inputs via Cable-Set
Low Level Signal Outputs via RCA
Additional Inputs
Auto Turn On Function
X-CONTROL 2 DSP-Software
Remote Controller with LED-Display
Fuse Rating
Dimensions (Width x Height x Length)
Technical specifications are subject to change! Errors are reserved!
OPTICAL
Scope of Delivery
1 x XE6440-DSP Amplifier
V2
REMOTE INPUT
1 x Remote Controller with LED Display, incl. Connection Cable
1 x USB Cable, A- to Mini-B Connector, 5 m
1 x System Cable-Set on ISO-Plug, 2 m
1 x Speaker Output Cable-Set (4-pin)
1 x Audio/AUX/REM Cable-Set (10-pin)
1 x CD-ROM with X-CONTROL 2 Software
1 x Owner's Manual (German/English)
OPTICAL
SPECIFICATIONS
XE6440-DSP
6
CLASS D Digital
4 x 40/60
4 x 80 /120
2 x 70/100
1 x 200
2 x 140/200
1 x 400
5 Hz - 20 kHz
> 100
> 90 dB
> 60 dB
0,05%
4 - 0,3 V
47 kOhms
13 Ohms with EPS protection circuit
Cirrus Logic Single Core 32 bit, 8-channel, 192 kHz
FL / FR / RL / RR
G (CH 7) / H (CH 8)
TOSLINK (HD Audio, optical, 12 ~ 96 kHz, stereo)
AUX (Cinch/RCA, stereo)
Switchable, ehile using, a + 12V turn on signal for additional devices is provided to the REM cable
for Microsoft Windows™
XP SP3, Vista, 7, 8, 8.1
10 Presets, Gain -40 ~ +12dB
6 x 31-Band Equalizer, 2 x 11-Band Equalizer, -18 ~ 12 dB, Q 0,5 ~ 9
Setting range 20 ~ 20.000 Hz (Outputs A-F), 20 ~ 200 Hz (Outputs G-H)
6 ~ 48 db/Oct. HP/BP/LP
Time Delay 0~15 ms/0~510 cm
Phase Shift 0°/180°
for Master Volume, Subwoofer Volume,
Input Selection, Mode Selection
1 x 20 A
120 x 40 x 216 mm
E / F / G / H HIGH LEVEL
LINE OUT
ON
AUTO TURN ON
PC CONNECT USB
ONLY WITH HIGH LEVEL INPUT
HIGH LEVEL
F+ E+
F - E -
V2
SPEAKER BAT T.
INPUT OUTPUT +12V
GND
OFF
SPEAKER BAT T.
INPUT OUTPUT +12V
XE4240-DSP
4-CHANNEL AMPLIFIER WITH
DIGITAL SOUND PROCESSOR
REM AUX
IN/OUT INPUT
XE6440-DSP
6-CHANNEL AMPLIFIER WITH
DIGITAL SOUND PROCESSOR
V2
PRT.
POW.
V2
