3. Plug the adaptor into the actuator.
(Fig. 16).
4. Mount the adaptor interface with four
allen screws onto the actuator. (Fig.
17).
5. Put the reducing bush onto the stem.
(Fig. 18).
6. Mount the actuator with the adaptor
interface on the connecting element.
(Fig. 19).
Fig. 16
Fig. 17
Fig. 18
Fig. 19
25/27
