5. Upgrade the CONTAIN-IT Plus Ball Valve Type 546 with an actuator
The CONTAIN-IT Plus Ball Valve can be upgraded with the EA11, EA21 and PA21 actuators
according to the following description. Please also follow the respective instructions.
To upgrade the CONTAIN-IT Plus Ball Valve you will need the Adaptor Set 700 238 796.
This Adaptor Set includes the following items:
•
1 x Adaptor Code 198 204 007
•
1 x Interface adaptor Code 198 803 156
•
2 x Reducing bush Code 198 803 145
Upgrades with other actuators on request.
5.1.
The upgrade of the actuators EA11, EA21 and PA21 follows the same steps.
1. Make sure that the red hand lever is
in parallel position to the pipe system.
(Fig. 14).
2. Loosen the nuts and remove the
hand lever. (Fig. 15).
Procedure
Fig. 14
Fig. 15
24/27
