1. Introduction

Double containment valves from +GF+ Piping Systems are supplied as a ready-to-install
system unit and the jointing technology used is similar to that for a double containment fitting.
The concept is that the inner pipe is first joined according to the jointing technology which
you have selected. The following jointing methods and materials can be chosen from:
Jointing methods for inner pipe
Butt fusion
IR fusion
Socket fusion
Solvent cementing
The following points are described in this manual:
•
installation and pressure testing of the CONTAIN-IT Plus ball valve
•
removing and reinstalling, e.g. in case of a leak
•
upgrade the valve with actuators.
Please note that the installation conditions and safety instructions contained
in the enclosed installation and operation instruction manual for the 2-way
ball valve type 546, manual operation, must be complied with each time the
double containment valve is built in or dismantled!
Material
PE100, PP-H, PVDF
PE100, PP-H, PVDF
PE80, PP-H, PVDF
PVC-C, PVC-U
