Fancom AT Anleitung Seite 9

Wiring connection
3
1
2
Cable entry:
ATM 7×0.8mm
AT 4×0.8mm
2.3 Install the protective screen (optional)
Turn the power supply off before cleaning or before carrying out any maintenance.
Before mounting the protective screen, make sure that the impeller is not turning.
+ s -
GND GND
IN 24
Connection box
Vortex damper
Direction Sensitive
RPM feedback
- DSR (ATM only)
Cable 7×0.14mm2
shielded
Terminal strip
1 2 3 4 5 6 7 7
- s +
IN 24
GND GND
(+) (-)
*
24Vac
control
Position feedback
AT motor
Trimming
potentiometer
max. stroke
Alignment lock
6
