6. Technical data

Mains connection
Motor rating
Operating mode
Compressor speed
Pressure vessel capacity
Operating pressure
Theoretical intake capacity
Effective delivery quantity at
1 bar
Protection type
Weight of the unit
Oil (15W 40) l
Max. altitude
(above mean sea level)
The noise emission values were measured in accord-
ance with EN ISO 3744.
Wear hearing protection.
The effects of noise can cause a loss of hearing.
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Sound power level L
wA
Sound pressure level L
pA
Uncertainty K
wA/pA
7.

Before starting the equipment

• Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• Prior to initial commissioning, remove the transport
plug (B) and fill the crank housing with oil as de-
scribed in item 8.4.
• Check the equipment for damage which may have
occurred in transit. Report any damage immediately
to the transport company which was used to deliver
the compressor.
• Install the compressor near the point of consump-
tion.
• Avoid long air lines and supply lines (extension ca-
• Make sure that the intake air is dry and dustfree.
230 V~ 50 Hz
• Do not install the compressor in a damp or wet
2200 W
S1
• The compressor may only be used in suitable rooms
2850 min
-1
50 l
approx. 10 bar
• The compressor is designed to be used in dry
approx. 412 l/min
approx. 294 l/min
• The oil level in the compressor pump has to be
IPX2
approx. 41.5 kg
• The compressor may only be used outdoor briefly
approx. 0.25 l
• The compressor must always be kept dry and must
1000 m

8. Attachment and operation

m Important!
You must fully assemble the appliance before using it
for the first time!
You will require the following tools for assembly and
installation:
• 2 x open-ended wrench size 17 mm (not included)
• 2 x open-ended wrench size 14 mm (not included)
91.3 dB(A)
71.2 dB(A)
8.1 Fitting the wheels (Fig. 5)
2.03 dB(A)
• Fit the supplied wheels (11) as shown.
8.2 Fitting the supporting foot (2x) (Fig. 6)
• Fit the supplied supporting foot (2x) as shown.
8.3 Fitting the air filter (2x) (Fig. 7, 8)
• Remove the transportation stop (A) and screw the
8.4 Changing the transportation cover (B)
• Remove the transport lid (B) of the oil filling open-
• Fill the included compressor oil into the crank hous-
www.scheppach.com
bles).
room.
(with good ventilation and an ambient temperature
from +5 °C to 40 °C). There must be no dust, ac-
ids, vapors, explosive gases or inflammable gases
in the room.
rooms. It is prohibited to use the compressor in ar-
eas where work is conducted with sprayed water.
checked before putting the equipment into opera-
tion.
when the ambient conditions are dry.
not be left outdoors after work is complete.
air filter (14) to the equipment.
(Fig. 9, 10)
ing (19).
ing and insert the included oil sealing plug (15) into
the oil filling opening (19).
GB | 25
