B. RX1 PRO SPECIFIC INSTALLATION
RX1 PRO is a fully programmable plug&play ECU. RX1 PRO is
the best solution both for original and modified engines: it is
possible to adjust the calibration map through both WiGET
App, by using the WiFi-COM device, and/or MAYA software.
WiGET App
RX1 Pro comes with 2 maps developed by GET R&D
Department, which can be easily switched thanks to the
Map Switch included in the kit.
REMEMBER TO WORK UNDER SAFETY CONDITIONS
AND TO KEEP THE ENGINE TURNED OFF.
1.
Remove the seat, the front
side panels, and move to the
left the fuel tank.
EN 4
2.
Find the OEM ECU: check
on your motorbike's workshop
manual where to find it. Press
the retainer clip of the OEM ECU
connector before pulling it: make
sure to remove the connector
without damaging it. Remove the
OEM ECU and the bracket with
the voltage regulator.
3.
Bend to 90° one brim of the
metal bracket and fix it back into
place.
4.
Cut away the extra rubber
from the ECU rubber support
5
90°
