oPeratIon oF rauworKs Front

Proceed as described below to commission the lifting door module.
a. Insert the power cable into a suitable plug socket.
The „RAUWORKS front" lifting door module is now ready for use!
b. Conduct a function test:
If you press the up arrow on the control element, the lifting door
goes up.
If you press the down arrow on the control element, the lifting door
goes down.
Note:
You must keep pressing the control element to open and close the
lifting door!
Caution!
Ensure that there are no persons in the traverse path of the lifting door
module (e.g. bend into the cabinet) when moving the lifting door.
There is a risk that persons will be hit or limbs crushed.
Do not lean against the lifting door module and do not fix any heavy
objects to the lifting door.
The stability of the RAUWORKS front electric lifting door module may
be impaired and the product may be damaged or fall over.
B41604_RAUWORKS_front_elektr_Montageanleitung_DE_EN_FR3_eps.indd 21
All manuals and user guides at all-guides.com
Control element
c. Check that the safety stop is set up correctly. In the case of
downward movement, the lifting door must stop if the remaining
gap is still approx. 25 mm. Only when the down arrow is pressed
again and held will the lifting continue all the way down at a
reduced speed.
Note:
If the safety stop is not set up correctly, please contact your REHAU
sales office.
Warning!
Subsequent corrections or other work on the product must only be
carried out if the plug has been removed from the power supply.
