Rehau RAUWORKS FRONT B41604 Montageanleitung Seite 20

Attach the carcass cover
a. Attach the carcass cover to the carcass front using a 5 mm wide
dowel or biscuit (not included in the scope of supply) using the
corresponding grooves on the rear of the carcass cover profile.
RAUWORKS Front,
Gesamtsystem "Accoustic",
Montage der Korpusprofile ;
Geometrie aus REHAU-Zeichnung
PKS-16078 B vom 08.11.2012 ,
für Einbauanleitung.
M1:10
20
B41604_RAUWORKS_front_elektr_Montageanleitung_DE_EN_FR3_eps.indd 20
All manuals and user guides at all-guides.com
Carcass cover
08.11.12 Fa. REHAU AG+Co,
Konstruktion CCT-IS,
Kiessling 2424
Fitting the lifting door
a. Attach the lifting door to the lifting columns.
Caution!
Always use two people to carry the lifting door. Ensure that you have a
firm grip. Always carry it at the top and bottom. Only release the lifting
door once both sides are fully in place.
RAUWORKS Front,
Gesamtsystem "Accoustic",
Endmontage Akkustik-Front-Element ,
Geometrie aus REHAU-Zeichnung
PKS-16078 B vom 08.11.2012 ,
für Einbauanleitung.
M1:20
08.11.12 Fa. REHAU AG+Co,
Konstruktion CCT-IS,
Kiessling 2424
