RICOO R03 Montageanleitung Seite 9

Full Motion LED, LCD TV Wall Mount
2
x
CAUTION: DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
Please check BEFORE installation distance between mounting holes on your display!
This wall mount supports the following distance between holes:
Horizontally
Vertical / Perpendicularly
R03
S0354
All manuals and user guides at all-guides.com
VESA - Mounting holes
Horizintally
100x100 300x200
100x200 300x300
200x100 400x100
200x200 400x200
300x100 400x300
Vertical /
Perpendicularly
Display back
min. 70mm - max. 500mm
min. 70mm - max. 400mm
95kg
400x400
500x100
(209lbs)
500x200
500x300
MAX
500x400
ASSEMBLY MANUAL
v.17.07
Deutsch English
