Step 6
Tilt adjustment nut
R
15
±
Step 7 (optional, if the screen hangs not in the level after mounting.)
This Wall Bracket has a rotation function of the front panel. Therefore the screen is turnable +/-6° horizontally / vertically. This has the
advantage that you can align horizontally the screen at any time. To permit this function, the four adjusting screws on the front panel
are set in the factory so that you can adjust the screen straightly with your hands without loosen the screws which is possible without
extra tools. With this feature you can align the screen with your hands in a horizontal or in another desired position when swinging out
or folding of the bracket.
If the factory setting of the rotation function is too strong or free-moving: Thus you can regulate/control this by loosening or
tightening the shown screws.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
