Var.2: Wood stud mounting
1
Stud finder
Wood stud
0 x
A
6 x
B
6 x
C
6 x
G
• Make sure that mounting screws are anchored into the center of the studs. The use of a stud finder is highly recommended.
• Installers are responsible to provide hardware for other types of mounting situations.
• Installers must verify that the supporting surface will safely support the combined weight of the equipment and all attached
hardware and components.
All manuals and user guides at all-guides.com
2
5
Mark the exact location
G
C
B
Deutsch
1
Find the wood stud
with studfinder
2
of mounting holes.
3
Drill pilot holes
4
Screw the wall mount
onto the wall.
