Component checklist
IMPORTANT: Ensure that you have received all parts according to the component checklist prior to
installation. If any parts are missing or faulty, telephone your loacal destributor for a
replacement.
Wall mount, pre-assembled (x1)
Plastic bag
S10 (x6)
A
Plain washer (x4)
F
M5 x 30MM (x4)
K
Plastic bag (small)
M6 (x4)
P
All manuals and user guides at all-guides.com
Please note: The numbering on the plastic bag may differ / completely missing!
M8 (x6)
Metal washer (x6)
B
Plastic washer (x10)
M4 x 16MM (x4)
G
M6 x 30MM (x4)
M8 x 30MM (x4)
L
Please note: Some elements can already be preassembled from the factory on the rails.
Plastic washer (x4)
Q
10mm
Plastic spacer (x8)
C
D
M5 x 16MM (x4)
H
I
M8 x 50MM (x4)
M
N
(x2)
(x2)
R
S
3
Rail, pre-assembled (x2)
5mm
Plastic spacer (x8)
E
M6 x 16MM (x4)
J
Bubble level (x1)
O
Plastic forceps (x1)
