26 Installation Guide
Then edit the corresponding 'phone book entry'. On the 'Server' tab the server type
must remain set to 'PPP: Windows NT, Windows 95 Plus, Internet'. The 'Activate
LCP Extensions for PPP' option must be enabled. Activate 'TCP/IP' and 'IPX', if
required, as valid network protocols (i.e. if you would like to grant access to a Novell
server). NetBIOS remains unchecked for this example.
k Another click takes you to 'TCP/IP Settings'. Let the server assign the IP address and
name server address. Normally, you do not need to change these settings.
Select the 'Accept any validity verification (incl. unencrypted)' option on the
'Security' tab.

General settings

Some more settings
Depending on which Setup wizard you ran, your router may not have received a name yet.
While a name is not absolutely necessary for some functions, it is advisable to help you
maintain an overview of your equipment.
What's more, the subscriber numbers to which the router should respond have not been
defined. The device will thus accept incoming calls for any number. The router will
function correctly in this state. However, it will also answer calls not intended for it. We
thus recommend that you assign subscriber numbers.
The following table shows you how to configure these settings.
Parameter
Device-name
Password for the
configuration
Limit configuration
via LAN and WAN
Call numbers for
router operation
Call numbers for
LANCAPI operation
Call numbers for
telephony
operation
Password for
remote
management
(default access via
PPP)
ELSA LANCOM Office Router
with ELSA LANconfig
'Management' configuration area,
'General' tab
'Management' configuration area,
'Security' tab
'Management' configuration area,
'Security' tab
'Communication' configuration area,
'General' tab, Router interfaces
button
'LANCAPI' configuration area,
'General' tab
'Telephony' configuration area,
'General' tab, a/b Port settings
button
'Communication' configuration area,
'Remote sites' tab, PPP list button
via telnet/terminal program
set setup/name
set password
set setup/config-module/LAN-config
set setup/config-module/WAN-config
set setup/WAN-module/Interface-list
set setup/LANCAPI-module/
EAZ-MSN(s)
set setup/ab-module/Port-list/
EAZ-MSN(s)
set setup/wan/PPP/default
