Dear ELSA Customer,
This Installation Guide will help you to get online as quickly as possible. First please
check that the contents of the package are complete:
Item/router
WAN connection cable
Power supply
Configuration interface cable
Configuration cable adapter
BNC T-connector for Thin Ethernet
LAN connection cable
TAE6NF/RJ11 telephone adapter for a/b ports
Documentation
CD containing ELSA LANconfig , other software
and electronic documentation
First, we will show you how to connect your new router and how to install the ELSA
LANconfig configuration software under Windows 95, Windows 98 and Windows NT 4.0.
After that, we will explain, by means of three examples, how to configure common
applications in no time.
If this is all going too fast for you or if the technical terms are going right over your head,
then you can of course turn to your User Manual for further information (exhaustive
sample configurations, explanations of the software, glossary, etc.).
This ISDN router is intended for use on an ISDN Basic Rate Interface. The connection is
made using the RJ45/RJ45 cable supplied.
® ®
Windows , Windows NT and Microsoft
