20
Installation Guide
Learn to surf in two minutes: the Internet wizard
The setup wizard starts automatically on completion of the Basic Settings Wizard.
If the wizard does not start automatically, call it up with Tools
Start the 'Set up Internet access' wizard and select your online service or provider
in the next step. It will usually help to specify 'Default provider via PPP' if your
service provider is not listed.
The wizard then briefly requests the required data (ISP access number, user name
and password). Your router is now ready to access the Internet.
Step by step: which settings do you configure on the router?
Menu
Setup/WAN-module/Name-list
Setup/WAN-module/PPP-list
Setup/IP-router-module/
IP-routing-table
If your Internet provider has provided you with an address for connecting via a proxy
server, do not configure this address on the router but in the browsers of the individual
PCs.
ELSA LANCOM Office Router
Parameter
Comment or value
Device-name
A meaningful name of your choice.
Dialup-remote
ISP access number
Time Out
'90': specify the duration of each call unit for
(B1-DT, B2-DT)
this connection, enabling units to be used as
efficiently as possible.
WAN-Layer
Protocol used by the ISP (e.g. PPP-HDLC)
Device-name
As defined in the host list
Authent.
'none' because the router should not demand
a password from the ISP.
Key
Password for connection to ISP (case-
sensitive)
Username
User name for ISP (case-sensitive)
IP-address
'255.255.255.255' combined with the subnet
mask defines the default route. All unknown
addresses are searched for using this route.
IP-netmask
'0.0.0.0'
Router-name
Same as 'Device name' in the Name list.
Masquerade
'on' hides the company's local area network
behind the IP address assigned to the router
by the provider for this connection.
Setup Wizard.
