Technical data

Technical data
Operating voltage
Operating temperature
Surge protection
Power consumption in "standby mode"
(vehicle parked, engine off)
Power consumption in operation
Power consumption at 12 V signal
It is quite safe to install the EDM eco later in HGV's, buses and private cars if it is fitted by an
authorised dealer.
In this case the installation need not be approved and the vehicle documents need not be
amended. The units have been checked in this respect by DEKRA.
These units comply with the quality assurance standards currently in force. It is quite safe to install
the units under the above conditions. If necessary you can request the safety certificate from your
dealer (-> next page).
46
All manuals and user guides at all-guides.com
© Siemens VDO Trading GmbH
+12 V DC up to +24 V DC
-20 °C up to +70 °C
in the junction box
< 40 mA
< 100 mA
max. 0.8 mA
EDM eco
Operating instructions
TU00-1404-0311020
