Trip and driver meters

Switching between trip and driver meters

Selecting driver meters

The consumption display unit has 100 driver meters (meters 0 - 99).
After selecting a driver meter, the consumption display unit stores the journey data for the
currently selected driver until another driver meter is selected.
Although driver meters are saved in the consumption display unit, vehicle meters are stored in the
vehicle interface (-> 7, 18). The vehicle meters give you the opportunity to carry out vehicle-related
analyses using the EDM eco PC download office software (-> 8).
So that the driver meter data is correct, e. g. for EDM eco PC download software analyses (-> 8),
driver meter selection can be PIN-protected (-> 24).
22
All manuals and user guides at all-guides.com
Switch between displays using the
Trip meter
Driver meter
The figure on the right shows the driver meter currently selected, e. g. driver
meter number "  ".
© Siemens VDO Trading GmbH
EDM eco
Operating instructions
key:
