Summary of vehicle interface functions

As well as preparing and providing trip data for the consumption display unit, the vehicle interface
itself stores the following vehicle meter information:
• Total distance travelled [km]
• Average speed [km/h]
• Total fuel consumption [l]
• Total time [hh:mm]
• Average engine speed [rpm].
Vehicle data is stored in the vehicle interface regardless of whether a consumption display unit is
connected. This means that the EDM eco can also be used without a consumption display unit.
Figures from the vehicle meters can be displayed on the consumption display unit (-> 18) and
using a consumption display unit can be downloaded from the vehicle interface for further analysis
(-> 8). A consumption display unit can store trip data from up to 50 vehicle interfaces which can
then be transferred from the consumption display unit to the computer through the download
cable.
