Description of unit

Operating and display parts

1
13
12
10
All manuals and user guides at all-guides.com
2
3
4
5
6
7
8
9
10
11
© Siemens VDO Trading GmbH
1 Driver/ trip selection display (-> 22)
2 Driver meter display (-> 22)
3 Upper journey data display (-> 14)
4 Lower journey data display (-> 15)
5 Speed profile display (-> 11)
6 Consumption trend display (-> 11)
7 Time/ remaining driving time display (-> 17)
8 LED display (-> 12)
9
key - Time/ remaining driving time (-> 17),
switch to next figure when entering PIN number
(-> 24)
10
key - Driver/ trip selection (-> 22), reset vehicle
meter (-> 19), set display lighting (-> 26)
11
(Back) key and
set / delete second speed alarm value (-> 20)
12
(Enter) key
13
(Scroll) keys
EDM eco
Operating instructions
TU00-1404-0311020
