General
Safety
Prerequisites for The self-supply transformer is installed in the inverter after all the AC cabling work on the
installation inverter has been completed.
-
-
-
Scope of supply
Tools required -
-
8
WARNING! Work that is carried out incorrectly can cause serious injury and dam-
age. The activities described below must only be carried out by trained and qual-
ified personnel. Refer to the "Safety" chapter in the inverter installation
instructions.
All 6 AC cables must be connected to the inverter.
The AC cables must be fixed in place with strain-relief clamps.
The cover for the cable inlet opening must be fitted.
Slotted screwdriver
10 mm socket wrench
Not illustrated:
- 6 fuses 3.15 A / 440 V
- 3 fuses 32 A / 500 V
- 2 M6 x 16 mm screws
- 1 installation instructions
