8. PRODUCT MAINTENANCE

Should legal provisions in your country specify mainte-
nance intervals, these must be observed. The console
and handpiece may need to be returned for periodic
servicing.
For the spare parts described below, please refer to the
order form or contact your EMS authorized service center.

8.1. COOLING LIQUID CIRCUIT MAINTENANCE

replaced every year. Regular maintenance is
required for product to function properly.
1. Empty the cooling liquid circuit.
Refer to the Product Storage and Shipping section
for instructions on emptying the cooling liquid
circuit.
2.
Figure 73
3.
cover (A).
4. Push the colored ring with your left hand and simulta-
5.
Figure 74
Connect the tubes to the corresponding color.
The grey ring is on the left and the green ring is
on the right.
6.
B
A
Figure 75
