9.

Technical data

For the dimensions and weight, see the delivery note.
Supply voltage
Nominal voltage
Standby power at nominal voltage,
primary (typical)
Ambient temperature during operation
Permissible relative humidity
(for operation)
Storage and transport temperature
Permissible relative humidity
(for storage)
Protection class motor control unit
Protection class work table
IP class
Max. duty cycle
Nominal lifting speed of the drive columns
(decreases under max. load)
Noise emissions (unloaded desk)
Max lifting force (load capacity)
Stroke length
Max. power consumption, primary
Supply voltage
Nominal voltage
Standby power at nominal voltage,
primary (typical)
Ambient temperature during operation
Permissible relative humidity
(for operation)
Storage and transport temperature
Permissible relative humidity
(for storage)
Protection class motor control unit
Protection class work table
IP class
Max. duty cycle
Nominal lifting speed of the drive columns
(decreases under max. load)
Noise emissions (unloaded desk)
Max lifting force (load capacity)
Stroke length
Max. power consumption, primary
Motor control unit JCB36N2 (temp
220–240 V / 50–60 Hz
230 V / 50 Hz
approx. 0.1 W
5–40°C
5–80% (non-condensing)
-10°C to +70°C
5–80% (non-condensing)
II
II
IP 20
10% (2 min. on / 18 min. off)
35 mm/s
< 55 dB(A)
750 N
Min. 600 mm
400 W
Motor control unit JCB36NP2
220–240 V / 50–60 Hz
230 V / 50 Hz
approx. 0.1 W
5–40°C
5–80% (non-condensing)
-10°C to +70°C
5–80% (non-condensing)
II
II
IP 20
10% (1 min. on / 9 min. off)
150 mm/s
< 55 dB(A)
500 N
Min. 600 mm
800 W
77
(≈ 75 kg)
(≈ 50 kg)
