60 Anschluss und Stromversorgung

3.3.7.4 CANSAS-L-DO16-PH

Signal Linke Schraubklemme
1+
1-
2+
2-
3+
3-
4+
4-
5+
5-
6+
6-
7+
7-
8+
8-
OD 1
GND 1
5V 1
GND 1 LCOM 1/CHASSIS

3.3.7.5 CANSAS-L-DO8R-PH

Buchse
IN
ON
OFF
CHASSIS
© 2014 imc Meßsysteme GmbH
Rechte Schraubklemme
BIT 1
LCOM 1
BIT 2
LCOM 1
BIT 3
LCOM 1
BIT 4
LCOM 1
BIT 5
LCOM 1
BIT 6
LCOM 1
BIT 7
LCOM 1
BIT 8
LCOM 1
NC
LCOM 1
HCOM1
LCOM 2/CHASSIS
1 2 3
IN1 IN2 IN3
ON1 ON2 ON3
OFF1 OFF2 OFF3
- - -
Signal
BIT 9
LCOM 2
BIT 10 10+
LCOM 2 10-
BIT 11 11+
LCOM 2 11-
BIT 12 12+
LCOM 2 12-
BIT 13 13+
LCOM 2 13-
BIT 14 14+
LCOM 2 14-
BIT 15 15+
LCOM 2 15-
BIT 16 16+
LCOM 2 16-
NC OD 2
LCOM 2 GND 2
HCOM2 5V 2
GND 2
4 5
IN4 IN5
ON4 ON5
OFF4 OFF5
CHASSIS -
imc CANSAS Erste Schritte - Doc. Version 1.9 - 05.12.2014
9+
9-
6 7 8
IN6 IN7 IN8
ON6 ON7 ON8
OFF6 OFF7 OFF8
- - CHASSIS
