3.3.1.3 CAN/DSUB Stecker

ISO8, C12, DO16, DO8R, DO16R, DI16, DAC8, INC4
CAN/DSUB
Signal
DSUB-15 Pin Terminal
nummer
9 1
2 2
10 3
3 4
11 5
4 6
12 7
5 8
13 9
6 10
14 11
7 12
13
15 14
8 17
18
1, Gehäuse 15.16
* Index nur an CON1
** Ersatzweise für CAN/DSUB-STD (RELAIS) kann ACC/DSUB-REL4 verwendet werden, wobei OFF und ON vertauscht sind.
© 2014 imc Meßsysteme GmbH
-U4, - -U6, -U6D, -Pt100
U4D, -I4,- -I6,-T6
T4
Spannung, Spg.- RTD/ Pt100
Teiler, Strom,
Thermoelement
ISO8 C12 ISO8, C12
+IN1 +IN 1 +IN1
-IN1 -IN 1 -IN1
+IN2 +IN 2 +IN2
-IN2 -IN 2 -IN2
+IN3 +IN 3 +IN3
-IN3 -IN 3 -IN3
+IN4 +IN 4 +IN4
-IN4 -IN 4 -IN4
VCC +IN 5
GND -IN 5
+DOUT1 +IN 6
-DOUT1 -IN 6
CHASSIS CHASSIS CHASSIS
-DO16 -STD **
(RELAIS)
TTL-
Schalter
Ausgang
DO8R/
DO16
DO16R
BIT1 IN 1
BIT2 IN 2
BIT3 IN 3
BIT4 IN 4
BIT5 ON 1
BIT6 ON 2
BIT7 ON 3
BIT8 ON 4
+I1 OFF 1
-I1 OFF 2
+I4 HCOM OFF 3
-I4 LCOM OFF 4
+I2
-I2 LCOM NC
+I3 OPDRN NC
-I3
CHASSIS CHASSIS
imc CANSAS Erste Schritte - Doc. Version 1.9 - 05.12.2014
Signalanschluss
- DI -DAC -INC
TTL- ±10V TTL-
Eingang Ausgabe Eingang
DI16 DAC8 INC4
+IN 1 NC +IN 1X
+IN 2 OUT 1 -IN 1X
-IN 1/2 GND +IN 1Y
+IN 3 NC -IN 1Y
+IN 4 OUT 2 +IN 2X
-IN 3/4 GND -IN 2X
+IN 5 NC +IN 2Y
+IN 6 OUT 3 -IN 2Y
-IN 5/6 GND +INDEX*
+IN 7 NC -INDEX
+IN 8 OUT 4 +5V
-IN 7/8 GND GND
NC NC NC
NC NC NC
CHASSIS CHASSIS CHASSIS
