EKOM DK50 PLUS Benutzerhandbuch Seite 11

DK50 PLUS, DK50 2V
Tab. 2
6 – 8 bar
Nominal voltage / frequency
(*)
Performance
at 6 bar
Working pressure (**)
Max. current
Motor power
Air tank volume
Air quality – filtration
Maximum operating pressure
of safety valve
Noise level at 5 bar
Duty cycle
PDP drying performance at 7
bar
Time to fill air tank from 0 to 7
bar
Dimensions (net)
w x d x h
Net weight (***)
Classification under
EN 60601-1
Notes:
(*) When ordering, state the version of the compressor
(**) For other range of pressure consult with the supplier
(***) Information about the weight is for informative purposes only and applies to the product without any
additional accessories.
Dependence of compressor output on working pressure
07/2021
DK50 PLUS
230 / 115 /
V / Hz
50/60 60
Lit.min-1 70/80 80
bar 6.0 – 8.0
A 3.9/4.9 9
kW 0.55
Lit. 25
-
µm
bar 11.0
LpfA [dB] ≤ 66/68 ≤ 68
S1-100%
-
s 149/126 126
mm 460x500x708
kg 48
- 11 -
DK50 PLUS S DK50 PLUS/M DK50 PLUS S/M
230 / 115 / 230 /
50/60 60 50/60
70/80 80 60/70
6.0 – 8.0 6.0 – 8.0
4/5 9.1 4/5
0.55 0.55
25 25
- 0.1
11.0 11.0
≤ 47/50 ≤ 50 ≤ 66/68 ≤ 68 ≤ 47/50
S1-100% S1-100%
- ≤ +3°C
149/126 126 198/159 159 198/159
560x675x877 460x565x708
87 53
Class I.
NP-DK50 PLUS, 2V-14_07-2021-MD
115 / 230 / 115 /
60 50/60 60
70 60/70 70
6.0 – 8.0
9.1 4.1/5.1 9.2
0.55
25
0.1
11.0
≤ 50
S1-100%
≤ +3°C
159
560x675x877
92
