PLACEMENT
1. Intubate the patient with VivaSight
2 SLT or equivalent.
2. Deflate VivaSight-EB's cuff completely
using a 20 cc syringe.
3. Lubricate VivaSight EBB's cuff
4. Keep the VivaSight EBB cuff close, but
not in, the multi-joint connector.
Connect the VivaSight EBB tube connector
to VivaSight 2 SLT or equivalent.
5. Connect the ventilator to the anesthesia
circuit on the multi-joint connector.
6. Push VivaSight EBB into VivaSight 2 SLT
or equivalent. If resistance is felt during
insertion, pull VivaSight EBB backward
(avoiding pulling the tip into the multijoint
connector), and then push forward while
gently twisting VivaSight EBB.
7. Guide VivaSight EBB's cuff to the target
bronchus. The cuff's direction can be
changed by twisting the blocker tube
left or right.
8. After confirming the position of VivaSight
EBB cuff, using VivaSight 2 SLT camera,
inflate the cuff to block the target bronchus
and lock VivaSight EBB's tube with the
twist lock.
9. If required, open the evacuation port
following placement to deflate the lung
or administer oxygen.
REMOVAL
Deflate the VivaSight EBB cuff completely
before removing VivaSight EBB. Follow
proper protocol prior to removal.
1. Use a 20 cc syringe to completely
deflate the cuff.
2. Pull the syringe plunger back towards
the 20 cc mark.
3. Disconnect the syringe from the inflation
port without releasing the plunger.
4. Disconnect the VivaSight EBB from the
VivaSight 2 SLT or equivalent, and pull it
gently backward to extract it from the
SLT tube.
DISPOSAL
Discard VivaSight EBB in an appropriate
biohazard receptacle in accordance with
local regulations.
