EN GLI SH
If model is not equipped with side handle, grip drill
with one hand on the handle and one hand on the
battery pack.
NOTE: Side handle comes equipped on all models.
Forward/Reverse Control Button
(fi g. 1)
A forward/reverse control button (b) determines the
direction of the tool and also serves as a lock off
button.
To select forward rotation, release the trigger switch
and depress the for ward/re verse control button on
the right side of the tool.
To select reverse, release the trigger switch and
depress the forward/reverse control button on the
left side of the tool.
The center position of the control button locks the
tool in the off position. When changing the position
of the control button, be sure the trigger is released.
NOTE: The first time the tool is run after changing
the direction of rotation, you may hear a click on
start up. This is normal and does not indicate a
problem.
Worklight (fi g. 1)
There is a worklight (c) located on the foot of the
tool. The worklight is activated when the trigger
switch is depressed. When the trigger switch is
released, the worklight will stay illuminated for up to
20 seconds.
NOTE: The worklight is for lighting the immediate
work surface and is not intended to be used as a
flashlight.
Torque Adjustment Collar/Electronic
Clutch (fi g. 3–5)
Your tool has an electronic adjustable torque
screwdriver mechanism for driving and removing
a wide array of fasteners. Circling the torque
adjustment collar (e) are numbers. These numbers
are used to set the clutch to deliver a torque range.
The higher the number on the collar, the higher the
torque and the larger the fastener which can be
driven. To select any of the numbers, rotate until the
desired number aligns with the arrow.
Three-Speed Gearing (fi g. 1, 3–5)
The three-speed feature of your tool allows you to
shift gears for greater versatility. To select speed 1
(highest torque setting), turn the tool off and permit it
to stop. Slide the gear shifter (f) all the way forward.
Speed 2 (middle torque and speed setting) is in the
42
middle position. Speed 3 (highest speed setting) is
to the rear.
NOTE: Do not change gears when the tool is
running. Always allow the drill to come to a complete
stop before changing gears. If you have trouble
changing gears, make sure that the gear shifter is
engaged in one of the three speed settings.
If the speed shifter becomes stuck or is difficult to
select the desired gear, pull the trigger switch (a) to
rotate the motor. Then select the gear.
Keyless Single Sleeve Chuck
(fi g. 6–8)
WARNING: Do not attempt to tighten
drill bits (or any other accessory) by
gripping the front part of the chuck
and turning the tool on. Damage to
the chuck and personal injury may
result. Always lock off trigger switch
and disconnect tool from power source
when changing acces sories.
WARNING: Always ensure the bit is
secure before starting the tool. A loose
bit may eject from tool causing possible
personal injury.
Your tool features a keyless chuck with one rotating
sleeve for one-handed operation of the chuck. To
insert a drill bit or other accessory, follow these
steps.
1. Turn off tool and disconnect tool from power
source.
2. Grasp the black sleeve of the chuck (d) with
one hand and use the other hand to secure the
tool as shown in Figure 6. Rotate the sleeve
counterclockwise (as viewed from the front) far
enough to accept the desired accessory.
3. Insert the accessory about 19 mm (3/4") into
the chuck (fig. 7). Tighten securely by rotating
the chuck sleeve clockwise with one hand while
holding the tool with the other hand (fig. 8).
Continue to rotate the chuck sleeve until several
ratchet clicks are heard to ensure full gripping
power.
To release the accessory, repeat Steps 1 and 2
above.
Be sure to tighten chuck with one hand on the
chuck sleeve and one hand holding the tool for
maximum tightness.
