supervised by a person responsible for their
safety. Children should never be left alone with
this product.

Electrical Safety

The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of your mains.
Your D WALT charger is double insulated
E
in accordance with EN 60335; therefore
no earth wire is required.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
D WALT service organization.
E
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal in
the plug.
• Connect the blue lead to the neutral terminal.
WARNING: No connection is to be
made to the earth terminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.

Using an Extension Cable

An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor size
is 1 mm 2 ; the maximum length is 30 m.
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND ADJUSTMENTS
WARNING: Prior to assembly and
adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the battery pack.
WARNING: Use only D
packs and chargers.
Inserting and Removing the
Battery Pack from the Tool (fi g. 2)
NOTE: For best results, make sure your battery
pack is fully charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack (h) with the rails inside the
tool's handle (fig. 2).
2. Slide it into the handle until the battery pack is
firmly seated in the tool and ensure that it does
not disengage.
TO REMOVE THE BATTERY PACK FROM THE TOOL
1. Press the battery release button (i) and firmly
pull the battery pack out of the tool handle.
2. Insert battery pack into the charger as
described in the charger section of this manual.
FUEL GAUGE BATTERY PACKS (FIG. 2)
Some D
E
which consists of three green LED lights that
indicate the level of charge remaining in the battery
pack.
To actuate the fuel gauge, press and hold the fuel
gauge button (m). A combination of the three green
LED lights will illuminate designating the level of
charge left. When the level of charge in the battery
is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.
NOTE: The fuel gauge is only an indication of the
charge left on the battery pack. It does not indicate
tool functionality and is subject to variation based
on product components, temperature and end-user
application.
Variable Speed Switch (fi g. 1)
To turn the tool on, squeeze the trigger switch (a).
To turn the tool off, release the trigger switch. Your
tool is equipped with a brake. The chuck will stop as
soon as the trigger switch is fully released.
NOTE: Continuous use in variable speed range is
not recommended. It may damage the switch and
should be avoided.
Side Handle (fi g. 1)
WALT battery
E
The side handle (g) clamps to the front of the gear
case and may be rotated 360˚ to permit right- or
left-hand use. Side handle must be tightened
sufficiently to resist the twisting action of the tool if
the accessory binds or stalls. Be sure to grip the
side handle at the far end to control the tool
during a stall.
WALT battery packs include a fuel gauge
WARNING: To reduce the risk of
personal injury, ALWAYS operate
the tool with the side handle properly
installed. Failure to do so may result
in the side handle slipping during tool
operation and subsequent loss of
control. Hold tool with both hands to
maximize control.
